Programming Instructions
AC-015 Hardware Installation and Programming Manual 25
You must be in Normal mode to program the AC-015. The Mode LED
is green. Wrong or timed out entries reset the controller to the
Normal mode condition.
To exit programming, press # for two seconds. Three beeps are
generated and the system returns to Normal mode. A short press on #
also returns the system to Normal mode, and a long beep is heard.
This aborts the programming, but in some cases, such as Program
Function #7, data may have already been programmed.
Wrong entries during programming may also abort programming,
along with long beep generation.
All programming operations are done either from the onboard
keyboard or from the external reader. Programming proximity
employee codes requires using a proximity reader and proximity cards.
10.1 Entering Programming Mode
To begin programming the controller’s settings, the AC-015 must first
place into Programming mode. You may only enter Programming
mode from Normal mode; the controller does not permit entry to
Programming mode if the controller is in Bypass and Secure modes.
The factory default Programming code is 1234.
To enter Programming mode:
1. Press # for 2 seconds.
You hear a short beep.
The Mode LED turns off.
The Door LED turns red.
2. Enter the 4-digit Programming code.
If the Programming code is valid, the door
LED turns green and the AC-015 enters
Programming mode.
If the Programming code is NOT valid, the controller emits a loud
beep and does NOT enter Programming mode.
