Rosslare AC-015 Hardware Installation

Mounting the Controller
AC-015 Hardware Installation and Programming Manual 15
Figure 1: AC-015 Controller Layout
4. Mount the controller to the wall using the two screws provided in
the Installation Kit or use the screws provided with your US Gang
Box when mounting to a US Gang Box.
5. Wire the controller according to the diagrams on the next few
pages.
6. Return and secure the front case using the security screw and
security tool provided in the installation kit.
You now have mechanically installed the controller.
Door LED
Mode LED
3x4 Matrix
Keypad
Bell Button
Case Screw

Rosslare AC-015 Specifications

General

Brand	Rosslare
Model	AC-015
Category	IP Access Controllers
Language	English
