4 x Set-up and installation
ROTEX GCU compact -
13
GCU compact 5xx
Fig. 4-5 Connection dimensions GCU compact 5xx (view from behind)
A Front side
B Rear side
Gc GCU compact
Fig. 4-6 Connection dimensions GC
U compact 5xx (plan view)
ROTEX recommends the installation of gravity brakes
( 16 50 70) or syphoning (lead the connection lines
straight downward) of the potable water connections to
avoid an increased loss through cooling.
