5 About the units and options
5.1 Identification
NOTICE
When installing or servicing several units at the same time,
make sure NOT to switch the service panels between
different models.
5.1.1 Identification label: Outdoor unit
Location
Model identification
Example: RV L Q 05 CA V3
Code Explanation
RV Split outdoor pair heat pump
L Low water temperature – ambient zone: −10~
−20°C
Q Refrigerant R410A
05 Capacity class:
▪ 05=5 kW
▪ 08=8 kW
CA Series
V3 1~, 230 V, 50 Hz
5.1.2 Identification label: Indoor unit
Location
Model identification
Example: R HY HBH 05 AA V3
Code Description
R ROTEX model
HY HY=Hybrid indoor unit
HBH HBH=Hydrobox heating only
HBX=Hydrobox heating and cooling
05 Capacity class:
▪ 05=5 kW
▪ 08=8 kW
AA Series
V3 1~ 230 V, 50 Hz
5.1.3 Identification label: gas boiler
Location
*HYKOMB33AA
No:
Anno:
Type:
NOx classe:
C13,C33,C43,C53,C63,C83,C93
0063 BQ 3155
BE I2E(S), I3P
FR II2Esi3P
ES II2H3P
UK II2H3P
7,2 - 32,7
7,2 - 27,3
7,1 - 26,3
7,8 - 27,1
3
90
~230V-50Hz, 105W, IP44
8
5
PIN:
G20
G20
G20
G20
Qnw(Hi)
PMW
20 mbar
20 mbar
20 mbar
20 mbar
kW
kW
kW
kW
Qn (Hi)
Pn(80-60)
Pn(50-30)
bar
bar
°C
0063
2013
PMS
Tmax
Condensing boiler
Model identification
*HYKOMB33AA
No:
Anno:
Type:
NOx classe:
C13,C33,C43,C53,C63,C83,C93
0063 BT 3576
BE I2E(S)
FR II2Esi3P
GB II2H3P
7,6 - 32,7
7,6 - 27,0
8,2 - 26,6
3
90
~230V-50Hz, 55W, IP44
8
5
PIN:
47-464-01
G.C.:
G20
G20
G20
Qnw(net)
PMW
20mbar
20mbar
20mbar
ES II2H3P
G20
20mbar
kW
kW
kW
bar
Qn (net)
Pn
PMS
bar
°C
0063
2013
Tmax
Condensing boiler
b
i
j
a
c
d
e
f
k
l
m
n
o
p
q
r
g
h
a
Model
b
Serial number
