16 Technical data
Installer reference guide
89
RVLQ05+08CAV4 + RHYHBH05AA + RHYHBH/X08AA +
RHYKOMB33AA
ROTEX HPU hybrid
4P355635-1 – 2013.05
16.1.2 Dimensions and service space: Indoor unit
a
c
m
n
o
o
p
e
k
l
h
j
i
fg
d
b
48251
79
12735
63
243
130
45
178
33
195 215
55
65 76
186
55121
350
139 200
450
405
105
121
3D082233-1
a
Gas pipe connection Ø15.9 mm flare
b
Liquid pipe connection Ø6.35 mm flare
c
Safety valve (pressure)
d
Air purge (automatic)
e
Water filter
f
Water inlet connection (Ø22 mm)
g
Water outlet connection (Ø22 mm)
h
Domestic hot water inlet connection (Ø15 mm)
i
Domestic hot water outlet connection (Ø15 mm)
j
Gas connection (1/2")
k
Wiring intake area heat pump module
l
Condensate drain (Ø25 mm flexible)
m
Flue pipe/air supply (Ø60/100 mm concentric)
n
Air purge boiler (manual)
o
Copper clamp connection 22 mm (accessory)
p
Boiler cover (option)
Note: Typical field installation is according to local and national regulations.
