rotork CML Series User Manual

26
Installation & Maintenance Instructions
7.0 Basic Setup
7.6 Select Action at End of Travel (cont'd)
CA LIM shows the actuator is set for Position Limit action at
the Closed end of travel.
To change the end of travel action press ENTER.
The actuator is now in EDIT Mode.
Use the UP/DOWN buttons to select the required end of
travel action.
Fig 7.19 shows the Closed End of Travel Action set to FRC
(FORCE) and the set output closing thrust will be applied to
the valve seat at the end of travel.
Press ENTER to save any changes.
Press CANCEL to return to previous menu.
NOTE Ensure that any changes to parameters are
SAVED before returning to VIEW Mode.
Use the UP/DOWN Buttons to select the Open Action
(OP ACT) and repeat the procedure to select the Action at
End of Travel.
AFTER SAVING ANY CHANGES PRESS CANCEL UNTIL
YOU HAVE RETURNED TO THE TOP LEVEL BASIC MENU
AND POSIT IS DISPLAYED.
LOCAL
OP ACT
X
X
X
X
VIEW
LOCAL
CA LIM
EDIT
LOCAL
CA FRC
LOCAL
CA LIM
VIEW
LOCAL
SAVED
VIEW
LOCAL
POS I T
EDIT
Fig 7.17 View close action value
Fig 7.18 Close on position limit
Fig 7.19 Close on force limit
Fig 7.20 Save new value
Fig 7.21 Open action setting
Fig 7.22 Default display
