52
SCROLL MESSAGES
The following outlines the types of scrolling messages that can be programmed:
1. OFF message – Message that runs in the OFF position
2. MODE message – Message that runs during the idle state in PRG, X, Z modes
3. SALES message – Message that runs after the sales transaction
4. IDLE message 1 – Message that runs during the idle state in REG modes *
5. IDLE message 2 – Message that runs during the idle state in REG modes *
* IDLE messages 1 and 2 can be combined for 1 longer message.
Each scroll message can be programmed for a maximum of 42 characters. Messages 4 and 5 (IDLE messages)
can be combined for a maximum of 84 characters.
TO PROGRAM A MESSAGE:
1. Turn the key to the "PRG" (PROGRAM) position.
2. If a PRG/Z Manager Password has been programmed, TYPE the (PASSWORD #), then PRESS the
[CLERK] key, or if you did not program a PRG/Z Manager Password, go to Step 3.
3. ENTER (6), PRESS (the message number), PRESS the [RETURN] key, begin inputting characters using
the alpha keyboard (Department keys) or the Alphanumeric Code Chart, if needed, (see Page 47). If a
wrong character is entered, use the [EC] key to "backspace" and delete that character and then continue.
Remember, the[ DEPT] key accesses the letters in the lower green section of the Department keys.
4. PRESS the [CHECK/STUBS] key to finalize.
“PRG” + (6n) + [RETURN] + (xxx…xxx) + [CHECK/STUBS]
(42 characters max)
EXAMPLE: To program the OFF (SCROLL MESSAGE #1) message:
“PRG” + (6) + (1) + [RETURN] + (Message) + [CHECK/STUBS]
(42 characters max)
EXAMPLE: To program the MODE (SCROLL MESSAGE #2) message:
“PRG” + (6) + (2) + [RETURN] + (Message) + [CHECK/STUBS]
(42 characters max)
EXAMPLE: To program the SALES (SCROLL MESSAGE #3) message:
“PRG” + (6) + (3) + [RETURN] + (Message) + [CHECK/STUBS]
(42 characters max)
EXAMPLE: To program the IDLE(SCROLL MESSAGE #4 or 5) message:
“PRG” + (6) + (4 or 5) + [RETURN] + (Message) + [CHECK/STUBS]
(42 characters max)
