Ruida Technology RDV6442G - Section 4: Interface Signal Description; Main Power Source Interface (CN0); Panel Signal-Cable Interface (HMI); Udisk Interface

RDV6442G Control System manual V1.3
SHENZHEN RUIDA TECHNOLOGY
10
Section 4 Description of
Interface Signal for
MainBoard
CONTENTS:
Interface of Main Power
Source CN0
Panel Signal-Cable
Interface HMI
Udisk Interface
PC-USB Interface
Ethernet Interface
General Output Port CN1
General Input Port CN2
