RDV6442G Control System manual V1.3
SHENZHEN RUIDA TECHNOLOGY
●Read Udisk: read the file list in the Udisk;
●
Copy to memory: copy the target Udisk file to the memory;
●Delete: delete the selected Udisk file;
This system supports such file formats of Udisk as FAT32 and FAT16, but it
can identify them when the files are put under the root directory of Udisk. The
file name of more than 8 characters will automatically be cut out by the
system. The file name that has only English letters and digits will not show
when they are copied to the mainboard. The files copied from the mainboard
to Udisk will be placed under the root directory of Udisk.
8.5 Introduction to some alarm info
When users are operating the system, or when the machine is running, some alarm information such
as water protecting error maybe shows as below:
Push “Enter” key or “Esc” key, the system will execute some relative steps.
