EmergencyInformation

EngineCompartmentFuseBox

FL8

FL1

FL12

FL14

FL7

FL1

FL3

FL5

R10

FL9

FL11

FL1

FL15

FL16

Thefuseboxislocatedontheleftsideoftheengine

compartment.Pressthecatch(arrowedinillustration)to

releasethehingedcover.

Note:Ownersareadvisedagainstremovingor

replacingthefusiblelinksinthefusebox.Failureof

anyoftheseitemsshouldbeinvestigatedbyanMG

AuthorisedRepairer.

FusesSpecications

CodeSpecications

Function

10A

DippedBeamRH

F25A

PostOxygenSensor,Cam

Solenoids

F310A

DippedBeamLH

F410A

AirConditioning

CompressorClutch

5AEMS

F65A

CoolingFanRelay,Air

ConditioningCompressor

ClutchRelay

30A

FrontWipers

F85APreOxygenSensor

F915A

FrontFogLamps

F1010A

MainBeamRH

F11

10A

MainBeamLH

135
