MainBeamIndicator-Blue
Illuminateswhentheheadlightsareswitchedto
mainbeam.
SideLightIndicator-Green
Illuminateswhenthesideorheadlightsare
switchedon.
DirectionIndicators-Green
Theleftandrightdirectionindicatorsare
representedbydirectionalarrowslocatedatthetopofthe
instrumentdisplay.Thewarninglightsashsynchronised
withtheexteriorleftorrightdirectionindicatorlights
whenevertheyareoperating.
Ifthehazardwarninglightsareoperated,bothwarning
lightswillashtogether.
Ifeitherwarninglightashesveryrapidly,thismeansthat
oneofthefrontorreardirectionindicatorlightsisnot
operating.
Note:Failureofasiderepeaterlightwillhavenoeffect
onthewarninglightashfrequency.
FrontFogLightIndicator-Green
Illuminateswhenthefrontfoglightsare
switchedon.
