SAJ VM1000 User Manual

VM1000 Series

‐61‐

limit applied requirements analog signal
F5.24
AI2 setting
value
correspondin
g to AI2
lower limit
-100.0% ～
+100.0%
Setting according to the
applied requirements
Used for checking
analog signal
F5.25
AI2 upper
limit
F5.18 ～
+10.00V
Setting according to the
applied requirements
Used for checking
analog signal
F5.26
AI2setting
value
correspondin
g to AI2
upper limit
-100.0% ～
+100.0%
Setting according to the
applied requirements
Used for checking
analog signal
F9.00
PID given
source
setting range：0～
6
0 indicates
function code
F9.01 given
Factory value has been
set as 0, namely set
F9.01 as digital setting
Keep the factory
value unchanged
F9.01～
F9.32
other
parameters in
PID group
-100.0% ～
100.0%
Set and adjust according
to the applied
requirements
Some parameters
need to be adjusted
in order to get the
proper value
Table 4-7 VM1000 PID Control Parameters








