Salus QUANTUM SQ610RF User Manual

52
7.4 Pairing with RX10RF receiver
3
Open the ZigBee network
OR
5 sec.
5 sec.
2
4
7
Press button for 3 seconds to expand
“SYSTEM TYPE” menu.
5
Use or buttons to:
- choose pairing with the RX10RF receiver in
the „RX1” conguration, if the receiver is set as
RX1 (receiver responds to the heating signal
from any thermostat),
- choose pairing with the RX10RF receiver in
the „RX2” conguration, if the receiver is set as
RX2 (receiver responds to the heating signal
from only one thermostat).
Conrm by button
6
Select your language by or
buttons and conrm by
button.
Now thermostat is looking for the
signal from the coordinator...
After all you will see the main
thermostat’s display.
1
PLEASE NOTE!
For easier installation, please make sure you have already added RX10RF receiver to your ZigBee network (please refer to the RX10RF receiver manual
instruction).
Close the ZigBee network
OR
5 sec.
5 sec.
3
3
