Sam4s ER-5200M Service Manual

2 Product Specifications
2-6 SAM4S ER-5200 Series
2-3 Thermal Printer Specifications
2-3-6 Printer Connector
Pin No. Signal Description Remark
1 Lever Sensor
2 GND
CN8
Table2-6 Printer Cover Open Switch Pin Assignment
Pin No. Signal Description
Remark
1 Phase B
2 Phase B-
3 Phase A
4 Phase A-
CN3
Table2-7 Printer Line Feed (Paper Feed) Motor Pin Assignment
Pin No. Signal Description Remark
1 Paper End Sensor LED Current Limit Signal
2 Paper End Sensor Input Signal
3 VCC
CN4
Table2-8 Printer Paper End Sensor Pin Assignment
Pin No. Signal Description Remark
1 VCC
2 Paper Near Sensor Input Signal
3 Paper Near Sensor LED Current Limit Signal
CN5
Table2-9 Printer Near End Sensor Pin Assignment
Pin No. Signal Description Remark
1 VCC
2 Black Mark Sensor Input Signal
3 Black Mark Sensor LED Current Limit Signal
CN6
(Printer Discon Check)
Table2-10 Black Mark Sensor Pin Assignment
Pin No. Signal Description
Remark
1 Auto Cut Motor DC Out#2
2 Auto Cut Motor DC Out#1
3 Auto Cut Sensor Input Signal
4 GND
CN7
Table2-11 Auto Cut Motor & Sensor Pin Assignment
