9 Exploded Views and Parts List
SAM4S ER-5200 Series 9-7
9-1 Main Set
9-1-2 Parts List
9-1-2-(e) Case Lower Assembly
No. Parts No. Description / Specification Q`ty Design-Location Serviceable Remark
E-15 6006-000195 SCREW-ASS'Y TAPPING: WS,BH,+,M4,L10,ZPC 2 Y
JK26-00015A TRANS-POWER:USA: 120V 60Hz 1 Y
E-16
JK26-00014A TRANS-POWER:EUROPE: 230V 50Hz 1 Y
E-17 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 5 Y
E-18 JK92-01227A PBA SUB-POWER 1 Y
E-19 JK39-00037A CBF HARNESS-I/F 1 Y
E-20 JK39-00039A CBF HARNESS-RS232 1 Y
E-21 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 3 Y
JK92-00948B PBA SUB-I/F 232 1 Y ER-52XX
E-22
JK92-00948E PBA SUB-I/F 232(SERIAL3) 1 Y ER-5240F
E-23 6003-001149 SCREW-TAPTITE: PWH,+,2,M4,L10,ZPC(YEL) 1 Y
E-24 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 1 Y
E-25 JK72-40389A PMO-HOLDER COVER/PRT: HIPS(V0) 1 Y
E-26 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 1 Y
E-27 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 1 Y
E-28 6006-000199 SCREW-ASS'Y TAPPTITE: WS,BH,+,M4,L8(ZPC) 1 Y
E-29 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 1 Y
E-30 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 1 Y
E-31 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 2 Y
E-32 JK70-10417A IPR-GROUND PLATE: SECC T1.0 1 Y
JK39-10002A CBF-POWER CORD: AUSTRALIA 1 Y
JK39-10003A CBF-POWER CORD: USA 1 Y
E-33
JK39-10008A CBF-POWER CORD: UK 1 Y
E-34 6002-000174 SCREW-TAPPING 2 Y
E-35 JK92-01227B PBA SUB-POWER SW 1 Y
E-36 6002-000171 SCREW-TAPPING: PH,+,2S,M4,L10,ZPC(YEL) 1 Y
E-37 JK70-10002A IPR-BRKT CASING: SBHG, T1.6 1 Y
JK72-20025A PMO-CASE LOWER: HIPS(V0),SERIAL 1 1 Y
ER-52XX
E-38
JK72-20025C PMO-CASE LOWER: HIPS(V0),SERIAL 1~3 1 Y
ER-5240F
E-39 JK39-00008A CBF-HARNESS-POWER S/W 1 Y
E-40 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 4 Y
JK92-01226A PBA MAIN-BOARD: ER-5500/EUROPE 1 Y
JK92-01226B PBA MAIN-BOARD: ER-5215,5240,5200/USA 1 Y
E-41
JK92-01226C PBA MAIN-BOARD: ER-5215,5240,5200/EUROPE 1 Y
E-42 JK96-00114A ASSY CLERK 1 Y
JK72-40360A PMO-COVER FRONT: HIPS(V0);NON CLERK 1 Y
E-43
JK72-40361A PMO-COVER CLERK KEY: HIPS(V0):WITH CLERK 1 Y
E-44 JK39-40563A CBF HARNESS-D/W: DRAWER CONNECTOR 1 Y
E-45 JK60-00001A SCREW-ASSY TAPTITE:-,SWRCH18A,M3,L8-WT-B 1 Y
E-46 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10 1 Y
E-47 JK70-20017A IPR-BRKT SPOOL: ER-5200,SECC T0.8 1 Y
E-48 6003-000198 SCREW-TAPPING: PWH,+,2,M3,L12,ZPC(YEL) 2 Y
Y JK39-40011A
CBF-GND WIRE: GND WIRE
(WITH AUTO CUTTER)
1 Y
Z JK39-40011A CBF-GND WIRE: GND WIRE 1 Y
To Next Page
