Sam4s ER-5200M Service Manual

SAM4S ER-5200 Series 2-1
2 Product Specifications
Specifications are correct at the time of printing. Product specifications are subject to change without notice.
See below for product specifications.
2-1 General Specifications
Item Description Remark
Processor
• MITSUBISHI M16C/80 Group M30800SFP (16 Bit)
External ROM Version
Memory
• RAM
SRAM (KM681000) : 1MBITs or 2MBITs
SRAM (KM684000) : 4MBITs × 2EA(Option)
• ROM
Flash ROM : 8MBITs (AM29F800)
Battery
• Type : Ni-MH, 3.6V 60mAh
• Charging Time : 24 Hours
• Life : 3 Years
Data Storage
• 60 Days
When battery is Full
charged
Interface Serial
(RS-232C)
• Flow Control :
① DTR / DSR : H/W Flow Control
② XON / XOFF : S/W Flow Control
• Baud Rate : 1200 / 2400 / 4800 / 9600 / 19200 Bps
• Connector : DB9P Female (I/F PBA)
• Voltage Supply : VCC(+5V/200mA) supplies at 9Pin of Connector.
RS-232C #1
RS-232C #2
Interface Serial
(IRC)
• Flow Control :
① XON/XOFF : S/W Flow Control
• Baud Rate : 9600 Bps
• Connector : Modular Jack Connector 12Pin (2 Port-6Pin)
Same as RS-485 2-Wire
Communication Method
Printer
• Model : Shin Heung STM-210
• Printing Speed : 50 mm / Sec (13.3 Line / Sec)
Detail Spec refer to Next
Page
Auto Cutter
• Type : Guillotine
• Cutting Method : 1 Point Partial Cutting
Display
• Operator Display : VFD (10 Digits) or 2 Line Character LCD
• Customer Display : VFD (10 Digits)
Key Board
• Flat Rubber Key : 160 Key (ER-5200 / ER-5200M)
• Raised Key : 60 key / 90 Key
(ER-5215 / ER-5240 / ER-5215M / ER-5240M)
Power Consumption
• Approx. 25W (Regularity)
Power Requirement
• AC 120V 60Hz, 230V 50Hz
Environment
Condition
• Temperature : 0℃ ~ 45℃
• humidity : 30% ~ 80% RH
Weight
• 15.2 Kg (SET), 17.6Kg(Box Packing)
Dimensions(mm)
• 400(W) × 455(L) × 305(H)
Table2-1 General Specifications
