Sam4s ER-5200M Service Manual

9 Exploded Views and Parts List
9-14 SAM4S ER-5200 Series
9-3 Auto Cutter (SAC-60)
9-3-2 Parts List
No. Parts No. Description / Specification Q`ty Design-Location Serviceable Remark
D JK96-10015A MEA-UNIT CUTTER: SAC-60;OPTION 1 Y
D-1 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 2 Y
D-2 JK70-50009A SCREW-MACHINE: RH,+,2,M2,L4,ZPC(WHITE) 4 Y
D-3 JK68-40003A LABEL(P)-WARNING CUTTER: TETRON T0.05 1 Y
D-4 JK72-20029A PMO-KNOB CUTTER: HIPS(HB),BLUE 1 Y
JK97-20003A COVER-CUTTER ASS’Y 1 y
Jk70-20008A IPR-COVER CUTTER: SPCC T1.2 1 N
D-5
JK70-70005A ICT-SHAFT UPPER CUTTER: SUM 24L 1 N
D-6 JK70-20009A IPR-MOVABLE BLADE 1 Y
D-7 JK70-50003A IPR-BUSHING CUTTER: SUM24L 1 Y
D-8 JK70-30003A SPRING CUTTER: SWP 1 Y
D-9 JK70-50013A SCREW-MACHINE: PWH,+,M2.6,L5.5,WHITE 1 Y
D-10 JK72-20031A PMO-GEAR KNOB: POM,NATURAL 1 Y
D-11 JK70-50009A SCREW-MACHINE: RH,+,M2,L4,ZPC 2 Y
JK97-20001A BOTTOM CUTTER ASS’Y 1 Y
JK70-20007A IPR-BOTTOM CUTTER: SECC T1.2 1 N
JK70-70002A ICT-SHAFT GEAR KNOB: SUM 24L 1 N
JK70-70003A ICT-SHAFT GEAR REDUCTION: SUM 24L 1 N
D-12
JK70-20004A ICT-SHAFT GEAR CAM: SUM 24L 1 N
D-12 JK70-20007A IPR-BOTTOM CUTTER: SECC, T1.2 1 Y
D-13 JK72-20033A PMO-GEAR CAM: POM,NATURAL 1 Y
D-14 JK70-50007A SCREW-MACHINE: RH,+,M1.7,L8 1 Y
D-15 3405-001014 SWITCH-MICRO 1 Y
D-16 JK39-40558A CBF-HARNESS-A/C: 4P,120MM 1 Y
D-17 JK72-20032A PMO-GEAR REDUCTION: POM,NATURAL 1 Y
JK97-20002A MOTOR ASS’Y 1 Y
JK59-40002A UNIT MOTOR ASS'Y: SAC-60 1 N
D-18
JK72-20030A PMO-GEAR MOTOR: POM 1 N
D-19 JK72-20028A PMO-HOLDER CUTTER: ABS 1 Y
