9 Exploded Views and Parts List
9-16 SAM4S ER-5200 Series
9-4 Key Board
9-4-1-(b) Parts List
No. Code No. Description Specification Q`ty Remark Serviceable
F JK59-30006A UNIT-KBD ASS'Y MEMBRANE,60 KEY:ER-5215 1
Y
F-1 JK72-40230A PMO-KBD HOUSING HIPS(VO),60 KEY 1
Y
F-2 JK81-10286D AS-KEY CAP S(1*1) PC,S-Z0513-71#01 1
Y
F-3 JK59-30006A LABEL KEY TOP - 1
N
F-4 JK81-10286C AS-KEY TOP S(1*2) ABS,302KAS-014-01 1
Y
F-5 JK81-10286B AS-CONTACT SPRING SUS304,601KAS-001-01 1
Y
F-6 JK81-10286A AS-RETURN SPRING(1*1) SWP-A,601KAS-005-01 1
Y
F-7 JK72-40310A PMO-COVER BLANK(1*1) HIPS(VO) 1
Y
F-8 JK72-40311A PMO-COVER BLANK(1*5) HIPS(VO) 1
Y
F-9 JK81-10286E AS-KEY CAP L(1*2) PC,S-Z0513-75#01 1
Y
F-10 JK72-40327A AS-KEY TOP L(1*1) ABS,302KAS-032-00 1
Y
F-11 JK61-70301A AS-RETURN SPRING(1*2) SWP-A,601KAS-016-01 1
Y
F-12 JK72-40324A PMO-HOLDER HOOK(A) POM,541KAS-001-01 1
Y
F-13 JK70-10382A IPR-SPACER KEYBOARD SUS304,321KAS-019-90 1
Y
F-14 JK72-40325A PMO-HOLDER HOOK(B) POM,541KAS-002-01 1
Y
F-15 JK72-40309A PMO-FRAME KEYBOARD POM,60 KEY,101KAS-054-01R 1
Y
F-16 6002-000175 SCREW-TAPPING PWH,+,2,M3,L8,ZPC(YEL) 8
Y
F-17 JK41-10100F FPC(60 KEY) 402KAS-101~102-01R 1
Y
F-18 JK70-10379A IPR-BASE PLATE(60 KEY) SECC T0.8,501KAS-032-01R 1
Y
F-19 6002-000147 SCREW-TAPPING PH,+,2,M3,L10,ZPC(YEL) 2
Y
JK72-40250A PMO-KEY CAP/1 ABS,302KAS-017-21 1
Y
JK72-40251A PMO-KEY CAP/2 ABS,302KAS-017-22 1
Y
JK72-40252A PMO-KEY CAP/3 ABS,302KAS-017-23 1
Y
JK72-40253A PMO-KEY CAP/4 ABS,302KAS-017-24 1
Y
JK72-40261A PMO-KEY CAP/5 ABS,302KAS-018-05 1
Y
JK72-40254A PMO-KEY CAP/6 ABS,302KAS-017-26 1
Y
JK72-40255A PMO-KEY CAP/7 ABS,302KAS-017-27 1
Y
JK72-40256A PMO-KEY CAP/8 ABS,302KAS-017-28 1
Y
JK72-40257A PMO-KEY CAP/9 ABS,302KAS-017-29 1
Y
JK72-40262A PMO-KEY CAP/0 ABS,302KAS-017-30 1
Y
JK72-40258A PMO-KEY CAP/00 ABS,302KAS-017-31 1
Y
F-20
JK72-40259A PMO-KEY CAP/. ABS,302KAS-017-32 1
Y
To Next Page
