9 Exploded Views and Parts List
9-18 SAM4S ER-5200 Series
9-4 Key Board
9-4-2-(b) Parts List
No. Parts No. Description / Specification Q`ty Design-Location Serviceable Remark
F JK59-30004A
UNIT-KBD ASS'Y: MEMBRANE,90 KEY;ER-5240/USA
1 Y
F-1 JK72-40231A PMO-KBD HOUSING: HIPS(VO),90 KEY 1 Y
F-2 JK81-10286D AS-KEY CAP S(1*1): PC,S-Z0513-71#01 1 Y
F-3 JK59-30004A LABEL KEY TOP: ER-5240/USA 1 N
F-4 JK81-10286C AS-KEY TOP S(1*1): ABS,302KAS-014-01 1 Y
F-5 JK81-10286B AS-CONTACT SPRING: SUS304,601KAS-001-01 1 Y
F-6 JK81-10286A AS-RETURN SPRING(1*1): SWP-A,601KAS-005-01 1 Y
F-7 JK72-40310A PMO-COVER BLANK(1*1): HIPS(VO) 1 Y
F-8 JK72-40311A PMO-COVER BLANK(1*5): HIPS(VO) 1 Y
F-9 JK81-10286E AS-KEY CAP L(1*2): PC,S-Z0513-75#01 1 Y
F-10 JK72-40327A AS-KEY TOP L(1*2): PC,S-Z0513-75#01 1 Y
F-11 JK61-70301A AS-RETURN SPRING(1*2): SWP-A,601KAS-016-01 1 Y
F-12 JK72-40324A PMO-HOLDER HOOK(A): POM,541KAS-001-01 1 Y
F-13 JK70-10382A
IPR-SPACER KEYBOARD: SUS304,321KAS-019-
90
1 Y
F-14 JK72-40325A PMO-HOLDER HOOK(B): POM,541KAS-002-01 1 Y
F-15 JK72-40312A
PMO-FRAME KEYBOARD: POM,90 KEY,101KAS-
055-01R
1 Y
F-16 6002-000175 SCREW-TAPPING: PWH,+,2,M3,L8,ZPC(YEL) 12 Y
F-17 JK41-10100K FPC(90 KEY): 402KAS-103~104-01R 1 Y
F-18 JK70-10380A
IPR-BASE PLATE(90 KEY): SECC T0.8,501KAS-
032-01R
1 Y
F-19 6002-000147 SCREW-TAPPING: PH,+,2,M3,L10,ZPC(YEL) 3 Y
JK72-40250A PMO-KEY CAP/1: ABS,302KAS-017-21 1 Y
JK72-40251A PMO-KEY CAP/2: ABS,302KAS-017-22 1 Y
JK72-40252A PMO-KEY CAP/3: ABS,302KAS-017-23 1 Y
JK72-40253A PMO-KEY CAP/4: ABS,302KAS-017-24 1 Y
JK72-40261A PMO-KEY CAP/5: ABS,302KAS-018-05 1 Y
JK72-40254A PMO-KEY CAP/6: ABS,302KAS-017-26 1 Y
JK72-40255A PMO-KEY CAP/7: ABS,302KAS-017-27 1 Y
JK72-40256A PMO-KEY CAP/8: ABS,302KAS-017-28 1 Y
JK72-40257A PMO-KEY CAP/9: ABS,302KAS-017-29 1 Y
JK72-40262A PMO-KEY CAP/0: ABS,302KAS-017-30 1 Y
JK72-40258A PMO-KEY CAP/00: ABS,302KAS-017-31 1 Y
F-20
JK72-40259A PMO-KEY CAP/.: ABS,302KAS-017-32 1 Y
To Next Page
