10 PCB Layout and Parts List
10-6 SAM4S ER-5200 Series
10-2 Power PCB Layout
10-2-2 Parts List
No. Parts No. Description / Specification Q`ty Design- Location Serviceable Remark
0502-000288 TR-POWER:KSD288,NPN,25W,TO-220,-,120-24 2 Q3,Q6
Y
1203-000391 IC-DC/DC CONVERTER:34063,DIP,8P,250MIL,P 2 U1,U2 Y
2401-001312 C-AL:4700uF,20%,50V,GP,BK,22x40,10 2 C7,C8 Y
JK27-60100D COIL FILTER:ER-350,140 UH,-,- 2 L8,L10 Y
JK96-01082B ELA ETC-HEAT SINK(5200):1010:ER-5200,BAS 1 N
0502-000234 TR-POWER:KSA1010Y,PNP,40W,TO-220,TP,100 2 Q9,Q10 Y
6002-000175 SCREW-TAPPING:PWH,+,2,M3,L8,ZPC(YEL) 2 HS1,HS2 Y
6203-000107 HEAT SINK:NONE,T2,W17,L22,H45,DEGRE,AL60 2 HS1,HS2 Y
JK94-00050A PHANTOM AU ER-5500 POWER BOARD 1 N
0402-000129 DIODE-RECTIFIER:1N4003,200V,1A,DO-41,TP 5 D1,D2,D3,D4,D5 Y
0403-000161 DIODE-ZENER:1N4751,5%,1000MW,DO-41,TP 1 ZD1 Y
2001-000027 R-CARBON:100OHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R1 Y
2001-000042 R-CARBON:1KOHM,5%,1/4W,AA,TP,2.4X6.4MM 6 R4,R5,R9,R10,R22,R23 Y
2001-000055 R-CARBON:4.7KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2 R2,R27 Y
R3,R6,R7,R8,R11,R12,R14,
2001-000065 R-CARBON:10KOHM,5%,1/4W,AA,TP,2.4X6.4MM 10
R15,R16,R17
Y
2001-000561 R-CARBON:27KOHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R29 Y
2001-000588 R-CARBON:3.3KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2 R24,R25 Y
2001-000855 R-CARBON:560OHM,5%,1/4W,AA,TP,2.4X6.4MM 2 R21,R26 Y
2004-000284 R-METAL:12Kohm,1%,1/4W,AA,TP,2.4x6.4mm 1 R28 Y
0501-000294 TR-SMALL SIGNAL:KSA708-Y,PNP,800mW,TO-92 3 Q1,Q2,Q11 Y
0501-000399 TR-SMALL SIGNAL:KSC945-G,NPN,250mW,TO-92 4 Q4,Q5,Q7,Q8 Y
C3,C4,C5,C6,C11,C12,C17,
2201-000119 C-CERAMIC,DISC:100nF,+80-20%,50V,Y5V,TP, 8
C18
Y
2201-000138 C-CERAMIC,DISC:100pF,10%,50V,Y5P,TP,4.0X 2 C15,C16 Y
2201-000162 C-CERAMIC,DISC:10nF,+80-20%,50V,Y5V,TP,7 2 C1,C2 Y
2401-000032 C-AL:100uF,20%,50V,GP,TP,8x12,5mm 2 C9,C10 Y
2401-001363 C-AL:470uF,20%,16V,GP,TP,10x12.5,5 2 C13,C14 Y
3301-000344 CORE-FERRITE BEAD:AA,-,3.5x0.6x6.5mm,-,- 8 L1,L2,L3,L4,L5,L6,L7,L9 Y
3602-000001 FUSE-CLIP:-,-,30mohm 2 FU1 Y
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 9 J1,J2,J3,J4,J5,J6,J7,J8,J9 Y
JK41-10545A PCB-POWER:ER-52/5500,FR-1,1L,T1.6mm,117X 1 POWER PCB Y
To Next Page
