Appendix
Code
no.
Parameter–Readings/
values [default setting]
Description
31* Position transmitter test
3)
–10.0to110.0%ofthe
operating range, [default
value is last indicated val-
ue of the position transmit-
ter], ESC
Testingthepositiontransmitter.Valuescanbeenteredinrelationto
the operating range.
The momentary valve position is used in initialized positioners
locally as the start value (bumpless changeover to the test mode).
Whentestingbysoftware,theenteredsimulationvalueisissuedas
the position feedback signal for 30 seconds.
3)
Analogpositiontransmitter:Code29/30/31canonlybeselectedifthepositiontransmitter(optional)isinstalled.
32* Error message in case of
'Function check' con-
densed state
[YES], No, ESC
YES: Error message also in case of 'Function check' condensed
state
No: 'Function check' condensed state does not cause an error
message to be issued
Note
Regardless of the condensed state, the fault alarm output always
switches when the error codes 57, 58, 60, 62 and 64 to 70, 76 are
issued.
33* Error message in case of
condensed state 'Mainte-
nance required'
[YES], No, ESC
YES: Error message only in case of condensed state 'Mainte-
nance alarm' and 'Maintenance required'
No: Error message only in case of condensed state 'Mainte-
nance alarm'
Note
Regardless of the condensed state, the fault alarm output always
switches when the error codes 57, 58, 60, 62 and 64 to 70, 76 are
issued.
34* Closing direction
CL, [CCL], ESC
CL: Clockwise
CCL: Counterclockwise
Direction of rotation to reach the valve's CLOSED position (view onto
rotary switch with positioner cover open).
Needs only be entered in SUb initialization mode (Code 6).
35* Blocking position
[0.0]mm/°/%,ESC
Enter the blocking position (distance to CLOSED position)
Only necessary with SUb initialization mode.
