Samson 373 Series User Manual

144 EB 8384-2 EN
SAMSON buttery valve linear (select
characteristic: 3)
SAMSON buttery valve equal percentage
(select characteristic: 4)
0
50
100
050 100
Travel/angle[%]
Setpoint[%]
0
50
100
050 100
Travel/angle[%]
Setpoint[%]
VETEC rotary plug valve linear (select
characteristic: 5)
VETEC rotary plug valve equal percentage
(select characteristic: 6)
0
50
100
050 100
Travel/angle[%]
Setpoint[%]
0
50
100
050 100
Setpoint[%]
Travel/angle[%]
Segmented valve ball linear (select
characteristic: 7)
Segmented valve ball equal percentage (select
characteristic: 8)
0
50
100
050 100
Travel/angle[%]
Setpoint[%]
0
50
100
050 100
Travel/angle[%]
Setpoint[%]
