Samson 373 Series User Manual

EB 8384-2 EN 87
Mounting and start-up
RefertoFig.33ortothelabelonthetermi-
nal block.
Malfunction due the current falling below
minimum current.
Do not allow the set point to fall below
3.8mA.
Accessories
Cable glands M20x1.5 Order no.
Black plastic
(6to12mmclampingrange) 8808-1011
Blue plastic
(6to12mmclampingrange) 8808-1012
Nickel-plated brass
(6to12mmclampingrange) 1890-4875
Nickel-plated brass
(10to14mmclampingrange) 1922-8395
Stainless steel 1.4305
(8to14.5mmclampingrange) 8808-0160
Adapter M20x1.5 to ½NPT Order no.
Powder-coated aluminum 0310-2149
Stainless steel 1400-7114
In positioners for attachment according to
VDI/VDE3847-1, the terminal designation
of the limit switches 41/42 and 51/52 as
well as the OPEN and CLOSED wording can
be changed by turning the terminal label
which is printed on both sides.
NOTICE
!
Note
