Samson 373 Series User Manual

92 EB 8384-2 EN
Operation
%
mm
AIR TO
OPEN CLOSE
INIT
CAUTION
VALVE
ACTUATES
MIN SIDE MAX BACK MIN BACK
MAX SIDE
Q
%
S
mm
%
S
mm
SERIAL INTERFACE
%
mm
Malfunction/fault
Manual mode
Closed-loop
operation
Code
Bar graph for set point
deviation or lever position
Units
Limit switch
Alarm 2
Fail-safe position active
Maintenance demanded
Maintenance required
Blinkingicon:outofspecication
Enable
Conguration
Designation
Position
Parameters
Limit switch
Alarm 1
AUtO
Automatic
CL
Clockwise
CCL
Counterclockwise
Err
Error
ESC
Stop
HI
ixhigherthan21.6mA
LO
ixlowerthan2.4mA
LOW
w too low
MAN
Manual setting
MAX Maximum range
No
Notavailable/notactive
NOM
Ratedtravel
O/C
Typeofapplication:On/offvalve
uEB8389
OVERLOAD
x>22mA
RES
Reset
RUN
Start
SAFE
Fail-safe position
SUb
Substitute calibration
tEStinG
Test function active
TunE
Initialization in progress
YES
Available/active
ZP
Zero calibration

Increasing/increasing

Increasing/decreasing
blinks
Emergency mode (see error code 62)
blinks
Initialization missing
S
Valveinmechanicalfail-safeposition
Fig.35: Display
