EB 8389-1S EN 15

Monitoring

Table 2: Resetting the diagnosis

Resetting

single status

messages

Code 36

Diag Std DS

Reference

graphs

Valve signature NO NO YES YES

Leakage sensor Manufacturer reference YES NO YES YES

Process reference YES NO YES YES

Data logger Conguration and measured values NO YES YES YES

Valve signature Signal pressure(x) Measured values YES YES YES YES

Course of supply pressure Conguration NO NO YES YES

Measured values YES YES YES YES

Friction(x) Measured values YES YES YES YES

On/off valve Conguration YES NO YES YES

Measured values YES YES YES YES

Valve position x histogram Measured values YES YES YES YES

Short-term monitoring 'Sampling time' and

measured values

YES YES YES YES

Set point deviation e histogram Measured values YES YES YES YES

Short-term monitoring 'Sampling time' and

measured values

YES YES YES YES

Cycle counter histogram Measured values YES YES YES YES

Short-term monitoring Measured values YES YES YES YES

Leakage sensor Short-term monitoring 'Sensitivity sound level'

and measured values

YES YES YES YES

Long-term monitoring Measured values YES YES YES YES

Sound level(x) Measured values YES YES YES YES

Course of lower end position Measured values YES YES YES YES

Reference value YES NO YES YES

Valve dead band Conguration and

measured values

YES YES YES YES

Partial stroke test (PST) Conguration and

measured values

YES NO* YES YES

* Except for 'Sampling time' parameter
