2. Panel
13
Λ
2-1. 1-way cassette type
(1) Accessories
(2) Installation
M4x12
tapped screw
(6)
M5x16 bolt (4)
Wireless remote
controller
(1)
Battery (2) STS 2S-2x10
tapped screw
(2)
Remote control
holder
(1)
Owner’s
instructions (1)
Installation
manual (1)
1) Open the front grille by pushing tabs on the grille.
2) Remove safety clips to open the grille completely.
3) Attach the panel to the indoor unit temporarily with 6 screws,
then adjust it to remove any gap the ceiling and the panel.
5-1.Installation_TM_E_06890 2/27/03 10:15 AM Page 13
