No. Name Description
1
2
3
4
5
6
7
8
Liquid pipe connection
Gas pipe connection
Drain pipe connection
Drain pipe connection
Power supply connection
Air discharge flange
Air suction flange
Hook
ø9.52(3/8”) Flare
ø19.05(3/4”) Flare
OD27.2/1 (1/16”) ID21.6 (7/8”) [without drain pump]
OD29/1 (1/8”) ID21 (13/16 ”
) [
without drain pump]
For M8~M10
ΙΙΙ . Indoor unit
5. Dimension
ΙΙΙ
34
5-5. Duct type (High pressure)
Unit : mm/inch
◆ If you want to install optional parts, refer to an appropriate installation manual.
