Exploded Views and Parts List
5-18Samsung Electronics
No. Code No. Description Specification SA/SNA
Q'TY
MGMH067IM
1 DB64-01143B PANEL FRONT HIPS 1 SNA
1 DB64-01421A PANEL-FRONT ABS,T3.0,WHT 1 SA
2 DB93-02803A ASS'Y PCB MAIN ASS'Y 1 SA
3 DB39-00082E CONNECT WIRE-DISPLAY PCB L990mm 1 SA
4 DB64-01422A BUTTON-PCB ABS,BLK 1 SA
5 DB64-01424A INLAY-PCB PC,WHT 1 SA
6 DB31-00285A MOTOR STEPPING 35BYJ46-276,800g .cm,12V 2 SA
7 DB39-00542E CONNECT WIRE-STEP MOTOR l320mm 1 SA
8 DB61-02485B BRACKET MOTOR-PANEL SGCC-M,T0.8 2 SA
9 DB66-01008A BLADE-H PBT/ABS,T3.5 4 SA
10 DB61-01871A CONNECTOR-BLADE POM,NTR 4 SA
11 DB61-02480A CONNECTOR-MOTOR A POM,NTR 1 SA
12 DB66-00756A JOINT UNIVERSAL POM,NTR 4 SA
13 DB66-01009A LINK-BLADE POM,NTR 2 SA
14 DB61-02488A BUSH-MINI POM,NTR 8 SA
15 DB65-10074D CLAMP-CABLE DA-4N 2 SA
16 DB65-00023A CLIP-WIRE-ASS'Y L130mm 1 SA
17 DB63-01364A COVER-A ABS(V0),BLK 1 SA
18 DB63-01366A COVER-B ABS(V1),BLK 2 SA
19 DB63-01377A COVER-C ABS(V2),BLK 1 SA
20 DB63-01036A COVER-KNOB HIPS,UL94-HB,WHT 2 SA
21 DB64-01145A KNOB-SLIDE HIPS,94HB,HG-0760,WHT 2 SA
22 DB67-00030A SPRING-KNOB STS304,T0.5 2 SA
23 DB69-01269A CUSHION-IN EPS,30 4 SA
24 DB69-01270A CUSHION-OUT EPS,30 4 SA
25 DB64-01420A GRILLE-AIR INLET ABS,WHT 1 SA
26 DB63-01423A FILTER-PRE MINI PP,BLK,ANTI BACTERIAL FILTER 1 SA
27 DB70-00302A PLATE-HANGER STS304,T0.5 2 SA
28 6002-000534 SCREW-TAPPING PH,2S,M3,L8,ZPC(BLK),SWRCH18A 1 SNA
29 6002-000536 SCREW-TAPPING PH,2S,M4,ZPC(YEL) 4 SNA
30 6002-001079 SCREW-TAPPING TH,2S,M4,L10 27 SNA
31 6011-001493 BOLT-HEX M6,L10,ZPC(YEL),SWRM18A 4 SA
32 DB61-02480B CONNECTOR-MOTOR B POM,NATURAL 1 SA
33 - WASHER - 1 SNA
■
Parts List
