Samsung mini DVM Series User Manual

Electrical Parts List
6-34Samsung Electronics
■ MAIN PCB : DB93-03809A
BD71 0402-001298 DIODE-BRIDGE DF06S,600V,1A,SMD-4,TP 1 SNA
C10,12,102,104, 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 32 SNA
201~203, 304~307,
314~316,401~403,413,
504~506,801,802,
806~808,815~819,902
C101 2401-002216 C-AL 2200uF,20%,35V,GP,TP,16x25,7.5 1 SNA
C103 2401-000711 C-AL 2200uF,20%,25V,GP,TP,16x25,7.5 1 SNA
C105 2401-000037 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 1 SNA
C204,205,441,911~914 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 7 SNA
C302,303,311~313 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 4 SNA
C901 2203-000444 C-CER,CHIP 1nF,10%,50V,X7R,2012 1 SNA
CD312,CD334 0406-001204 DIODE-TVS SMBJ5.0CA,6.4/-/7.07V,600W,SMB 2 SNA
CN10 3711-004182 CONNECTOR-HEADER BOX,10P,1R,2mm,STRAIGHT,SN,NTR 1 SNA
CN11 3711-000880
HEADER-BOARD TO CABLE BOX,3P,1R,2.5mm,STRAIGHT,SN,RED 1 SNA
CN31 3711-000177
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,RED 1 SNA
CN32 3711-000178
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,WHT 1 SNA
CN33 3711-000176
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,BLU 1 SNA
CN41 3711-000940
HEADER-BOARD TO CABLE BOX,4P,1R,2.5mm,STRAIGHT,SN,WHT 1 SNA
CN42 3711-000015
HEADER-BOARD TO CABLE BOX,2P,1R,2.5mm,STRAIGHT,SN,WHT 1 SNA
CN43 3711-000798 CONNECTOR-HEADER BOX,2P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN51 3711-000794
HEADER-BOARD TO CABLE BOX,2P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN62 3711-001001 CONNECTOR-HEADER BOX,5P,1R,2.5mm,STRAIGHT,SN,BLU 1 SNA
CN71 3711-003404
HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLU 1 SNA
CN72 3711-000203
HEADER-BOARD TO CABLE 1WALL,2P/3P,1R,7.92mm,STRAIGHT, 1 SNA
SN,WHT
CN74 3711-003406
HEADER-BOARD TO CABLE
1WALL,2P,1R,7.92mm,STRAIGHT,SN,YEL 1 SNA
CN75 3711-003405
HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLK 1 SNA
CN76 3711-001000
HEADER-BOARD TO CABLE BOX,5P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN77 3711-003407
HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,RED 1 SNA
CN78 3711-000262
HEADER-BOARD TO CABLE
1WALL,3P,1R,7.92mm,STRAIGHT,SN,WHT 1 SNA
CN81 3711-000939
HEADER-BOARD TO CABLE BOX,4P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN83 3711-000796
HEADER-BOARD TO CABLE BOX,2P,1R,2.5mm,STRAIGHT,SN,RED 1 SNA
CN91 3711-003845
HEADER-BOARD TO CABLE BOX,11P,1R,2mm,STRAIGHT,SN,WHT 1 SNA
D105 0402-000137 DIODE-RECTIFIER 1N4007,1KV,1A,DO-41,TP 1 SNA
D900~927 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP 28 SNA
F701 3601-000263 FUSE-CARTRIDGE 250V,3.15A,TIME-LAG,GLASS,5x20mm 1 SNA
F701_1 DB61-00924A HOLDER-FUSE -,FH-51B,-,-,-,-,SSEC 1 SNA
F702 3601-001308 FUSE 250V,1.6A,TIME-LAG,PLASTIC,8.4x7.6mm 1 SNA
FT71 DB27-00032A COIL CHOKE -,-,14mH MIN AT 1KHz(1V),-,-,-,2.5A, 1 SNA
ø19x11x13,-,20x28x20,-,ø0.5,480PCS/PACK,-
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
6-1-7 Duct type(Slim 1)
