Electrical Parts List
Samsung Electronics6-19
■ MAIN PCB : DB93-04122A
BD71 0402-001298 DIODE-BRIDGE DF06S,600V,1A,SMD-4,TP 1 SNA
BZ61 3002-001129 BUZZER-PIEZO 85DB,-,-,2KHz,- 1 SNA
C10,C12,C102,C104, 2203-000192 C-CERAMIC,CHIP 100nF,+80-20%,50V,Y5V,2012 32 SNA
C201,C202,C304~C307,
C314~C316,C401~C403,
C413,C504~C506,C701,
C801,C802,C806~C808,
C815~C819,C902
C101 2401-003895 C-AL 15uF,20%,450V,GP,TP,12.5x20mm,5 1 SNA
C103 2401-000151 C-AL 1000uF,20%,25V,GP,TP,10x20,5 1 SNA
C105 2401-001363 C-AL 470uF,20%,16V,GP,TP,10x12.5,5 1 SNA
C107,C108 2201-000987 C-CERAMIC,DISC 2.2nF,20%,400V,Y5U,BK,12.5x6mm,10 2 SNA
C203,C441,C702, 2203-001562 C-CERAMIC,CHIP 10nF,+80-20%,50V,Y5V,TP,2012 7 SNA
C911~C914
C302,C303,C312, 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 5 SNA
C313,C311
C601 2401-002300 C-AL 47uF,20%,50V,GP,TP,6.3x11,5 1 SNA
C901 2203-000444 C-CERAMIC,CHIP 1nF,10%,50V,X7R,2012 1 SNA
CD11 0406-001086 DIODE-TVS ST02D-200,185/200/215V,200W,DO-214 1 SNA
CD312,CD334 0406-001204 DIODE-TVS SMBJ5.0CA,6.4/-/7.07V,600W,SMB 2 SNA
CN10 3711-005716 CONNECTOR-HEADER BOX,10P,1R,2mm,STRAIGHT,SN,BLK 1 SNA
CN31 3711-000177 CONNECTOR-HEADER 1WALL,2P,1R,3.96mm,STRAIGHT,SN,RED 1 SNA
CN32 3711-000178 CONNECTOR-HEADER 1WALL,2P,1R,3.96mm,STRAIGHT,SN,WHT 1 SNA
CN33 3711-000176 CONNECTOR-HEADER 1WALL,2P,1R,3.96mm,STRAIGHT,SN,BLU 1 SNA
CN41 3711-000940 CONNECTOR-HEADER BOX,4P,1R,2.5mm,STRAIGHT,SN,WHT 1 SNA
CN42 3711-000015 CONNECTOR-HEADER BOX,2P,1R,2.5mm,STRAIGHT,SN,WHT 1 SNA
CN43 3711-000798 CONNECTOR-HEADER BOX,2P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN51 3711-000794 CONNECTOR-HEADER BOX,2P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN60 3711-000577 CONNECTOR-HEADER BOX,10P,1R,2.5mm,STRAIGHT,SN,WHT 1 SNA
CN62 3711-001001 CONNECTOR-HEADER BOX,5P,1R,2.5mm,STRAIGHT,SN,BLU 1 SNA
CN71 3711-003404 CONNECTOR-HEADER 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLU 1 SNA
CN74 3711-000203 CONNECTOR-HEADER
1WALL,2P/3P,1R,7.92mm,STRAIGHT,SN,WHT
1 SNA
CN75 3711-003405 CONNECTOR-HEADER 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLK 1 SNA
CN76 3711-001000 CONNECTOR-HEADER BOX,5P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN78 3711-000262 CONNECTOR-HEADER 1WALL,3P,1R,7.92mm,STRAIGHT,SN,WHT 1 SNA
CN81 3711-000939 CONNECTOR-HEADER BOX,4P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN83 3711-000796 CONNECTOR-HEADER BOX,2P,1R,2.5mm,STRAIGHT,SN,RED 1 SNA
CN91 3711-004712 CONNECTOR-HEADER BOX,9P,1R,2mm,STRAIGHT,SN 1 SNA
D101 0402-001194 DIODE-RECTIFIER SHG2D,200V,2A,-,TP 1 SNA
D900~D927 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP 28 SNA
F701 3602-001012 FUSE-BLOCK 500V,-,100m 1 SNA
