Samsung mini DVM Series - Mini 4 Way Cassette Type

Disassembly and Reassembly
4-26Samsung Electronics
No Parts Procedure Remark
1 Front Grille
– Dust-Collecting
Filter
1) Push the tap on the Front Grille to open it.
2) Disassembly of Front Grille.
(1) Open the Front Grille at about 45˚
degrees and draw it forward.
(2) Disassemble the safety Clip.
3) Filter Disassembly
(1) Draw the Dust-Collecting Filter
forward.
(2) Disassemble the Filter.
4-1-4 Mini 4 way cassette type
