13-2 Outdoor Unit (mini DVM Series)
Centralized Control
*Wired remote controller
*Transmitter
*Centralized Controller
485 Comm. Control (Non polarity)
Indoor Unit Setting Up(Option) S/W
Outdoor Unit Display
Key (Special Operation Control)
3 Phase Detection part
Outdoor Unit Temperature/Pressure
Sensor, Low-pressure Switch
Electronic Expansion Valve Control
Outdoor Unit Fan Control
Outdoor Unit Load Control
Comp, Bypass V/V, Sol V/V, CCH
Download
Transmitter Power (12V)
MAIN PCB
To Next Page
