Samsung mini DVM Series User Manual

Samsung Electronics6-1
■ MAIN PCB : DB93-03258B
BD71 0402-001298 DIODE-BRIDGE DF06S,600V,1A,SMD-4,TP 1 SNA
BZ61 3002-001129 BUZZER-PIEZO 85DB,-,-,2KHz,- 1 SNA
C10 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C102 2401-003895 C-AL 15uF,20%,450V,GP,TP,12.5x20mm,5 1 SNA
C103 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C104 2401-000151 C-AL 1000uF,20%,25V,GP,TP,10x20,5 1 SNA
C105 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C106 2401-001363 C-AL 470uF,20%,16V,GP,TP,10x12.5,5 1 SNA
C107 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C108 2201-000987 C-CERAMIC,DISC 2.2nF,20%,400V,Y5U,BK,12.5x6mm,10 1 SNA
C109 2201-000987 C-CERAMIC,DISC 2.2nF,20%,400V,Y5U,BK,12.5x6mm,10 1 SNA
C12 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C201 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C202 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C203 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C204 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C205 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C302 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C303 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C304 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C305 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C306 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C307 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C311 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C312 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C313 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C314 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C315 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C316 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C401 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C402 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C403 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C441 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C504 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C505 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C506 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C601 2401-002300 C-AL 47uF,20%,50V,GP,TP,6.3x11,5 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
6. Electrical Parts List
6-1 Indoor Unit
6-1-1 1 way cassette type
