Samsung Electronics
Exploded Views and Parts List
5-62
■
Parts List(cont.)
Q'TY
No.
Code No. Description Specification SA/SNA
42 DB96-05063A ASS'Y COND MAIN ASS'Y 1 SA
43 DB96-05066A ASS'Y TUBE COND OUT ASS'Y 1 SA
44 DB96-05068A ASS'Y TUBE COND IN ASS'Y 1 SA
45 DB59-00010A ASS'Y COMP FIX ZRD72KCE-TFD 2 SA
46 DB59-00009A ASS'Y COMP PWM ZRD72KCE-TFD 1 SA
47 DB93-03725A ASS'Y CONTROL PART ASS'Y 1 SNA
47-1 DB90-02149A ASS'Y COVER CONTROL BOX ASS'Y 1 SNA
47-2 DB90-02270A ASS'Y COVER CONTROL WIRE ASS'Y 1 SA
47-3 DB63-01361A COVER CONTROL IN ABS 5V 1 SA
47-4 DB63-01361B COVER CONTROL IN ABS 5V 1 SA
47-5 DB63-01361C COVER CONTROL IN ABS 5V 1 SA
48 DB93-03736G ASS'Y CONTROL BOX ASS'Y 1 SA
48-1 DB90-02269A ASS'Y CABI CONTROL BOX ASS'Y 1 SNA
48-2 DB93-03805A ASS'Y CONTROL IN ASS'Y 1 SNA
48-3 DB93-02756G MAIN PCB ASS'Y 1 SNA
48-4 DB93-02819A POWER PCB ASS'Y 1 SA
48-5 DB93-03531A CT PCB 1(COMP1) ASS'Y 1 SA
48-6 DB93-03531B CT PCB 2(COMP2) ASS'Y 1 SA
48-7 DB93-03531C CT PCB 3(COMP3) ASS'Y 1 SA
48-8 DB65-00208A TERMINAL BLOCK-3PHASE 4P(R S T N) 1 SA
48-9 DB65-00209A TERMINAL BLOCK-AC 2P 2P(L N) 1 SA
48-10 DB65-40062T TERMINAL BLOCK-4P 4P(F1 F2 OF1 OF2) 1 SA
48-11 DB35-00049A MAGNETIC CONTACTOR 240V/ 50Hz 3 SA
48-12 2901-001291 NOISE FILTER(LFM-215F) 250V,15A,50/60Hz 1 SA
48-13 DB26-10079H LINEAR TRANS(2TAP) AC230V,DC17V,1A 1 SA
48-14 DB93-01469A NOISE ABSORBER ASS'Y 1 SA
To Next Page
