Exploded Views and Parts List
5-38Samsung Electronics
■
Parts List
No. Code No. Description Specification SA/SNA
Q'TY
1 DB92-00447H ASS'Y PANEL FRONT-TOTAL ASS'Y 1 1 1 SA
1-1 DB92-00471A ASS'Y PANEL SUB ASS'Y 1 1 1 SA
1-1-1 DB92-00386A ASS'Y PANEL FRONT-SUB ASS'Y 1 1 1 SA
1-1-2 DB31-00195B MOTOR STEP - 1 1 1 SC
1-1-3 DB61-01114A HOLDER MOTOR DC HIPS 1 1 1 SA
1-1-4 DB61-01144A HINGE GRILLE HIPS 1 1 1 SA
1-1-5 DB61-01116A GUIDE LINK HIPS 1 1 1 SC
1-1-6 DB66-00366A LINK MOTOR ABS 1 1 1 SC
1-2 DB64-00670A GRILLE UP HIPS 1 1 1 SA
1-3 DB63-00596D FILTER-LF PP 1 1 1 SA
1-4 DB63-00597D FILTER-RH PP 1 1 1 SA
2 DB92-00449D ASS'Y GRILLE LOW SUB ASS'Y 1 1 1 SA
3 DB96-03798A ASS'Y EVAP-TOTAL ASS'Y 1 1 - SA
DB96-03798C ASS'Y EVAP-TOTAL ASS'Y - - 1 SA
4 DB95-00367F ASS'Y FILTER BIO ASS'Y 1 1 1 SA
5 DB63-00594A COVER TERMINAL HIPS 1 1 1 SA
6 DB93-03016N ASS'Y REMOCON ASS'Y 1 1 1 SA
7 DB94-00531A ASS'Y BACK BODY ASS'Y 1 1 1 SA
7-1 DB94-00040J ASS'Y CROSS FAN ASS'Y 1 1 1 SA
7-2 DB60-20011A BOLT SPECIAL M6 1 1 1 SA
7-3 DB31-10151C MOTOR-FAN IN - 1 1 1 SA
7-4 DB61-01135A BACK BODY HIPS 1 1 1 SNA
7-5 DB61-01136A HOLDER-MOTOR PP 1 1 1 SNA
7-6 DB63-00580A COVER-IONIZER HIPS 1 1 1 SA
7-7 DB73-00128A RUBBER BEARING - 1 1 1 SA
7-8 DB94-40007A ASS'Y BEARING-MOTOR - 1 1 1 SNA
8 DB67-60030A SPRING SENSOR - 1 1 1 SNA
9 DB70-00295A PLATE-HANGER SGCC-M 1 1 1 SA
10 DB93-03489B ASS'Y CONTROL IN ASS'Y 1 1 1 SA
11 DB61-01137A HOLDER-PIPE HIPS 1 1 1 SA
12 DB94-00300E ASS'Y TRAY DRAIN ASS'Y 1 1 1 SA
12-1 DB94-00062B ASS'Y DRAIN HOSE ASS'Y 1 1 1 SA
12-2 DB61-01141A BLADE-H ABS 1 1 1 SA
12-3 DB61-01142A BLADE-V PP 3 3 3 SA
12-4 DB63-00598A TRAY DRAIN ABS 1 1 1 SNA
12-5 DB31-00285A MOTOR-STEPPING BLADE - 1 1 1 SA
12-6 DB63-00699A GUARD-SAFETY WIRE - 1 1 1 SA
13 DB63-01284A COVER CONTROL IN SGCC-M 1 1 1 SNA
AVXWPH045E
✳
AVXWPH056E
✳
AVXWPH071E
✳
