Samsung mini DVM Series User Manual

Exploded Views and Parts List
5-48Samsung Electronics
■
Parts List
No. Code No. Description Specification SA/SNA
Q'TY
AVXTFH056E ✳ AVXTFH071E ✳
1 DB64-00682A CABI BASE ABS 1 1
2 DB63-00601A COVER PIPE ABS 1 1
3 DB63-00602A COVER SIDE ABS 2 2
4 DB61-01149A PLATE HANGER LF SGCC-M 1 1
5 DB61-01150A PLATE HANGER RH SGCC-M 1 1
6 DB61-01155A BRACKET COVER PIPE SGCC-M 1 1
7 DB64-00683A CABI FRONT ABS(SILK PRINT) 1 1
8 DB63-00606B COVER DISPLAY A ABS(SILK PRINT) 1 1
9 DB63-00607A COVER DISPLAY B PC 1 1
10 DB63-00604A COVER LED ABS 1 1
11 DB93-01716A DISPLAY PCB IN PCB 1 1
12 DB61-01159A CASE DISPLAY PCB ABS 1 1
13 DB66-00451A LATCH PUSH ASS'Y 3 3
14 DB64-00684A INLET GRILLE ABS 1 1
15 DB63-00610A FILTER AIR PP 2 2
16 DB61-01153A PLATE HANGER FRONT SGCC-M 1 1
17 DB61-01156A BRACKET OUTLET ABS 1 1
18 DB31-00158A BLADE V ABS 12 12
19 DB31-00159A BLADE CONNECTOR V ABS 2 2
20 DB31-00164A BLADE CONNECTOR H ABS 2 2
21 DB31-00157A BLADE H ABS 1 1
22 DB31-10153D SWING MOTOR IN ASS'Y 1 1
23 DB61-01352A BRACKET DRAIN SGCC-M 1 1
24 DB67-00258A DRAIN SUB LF SGCC-M 1 1
25 DB67-00259A DRAIN SUB RH ABS 1 1
26 DB75-00247A EVAPORATOR ASS'Y 1 1
27 DB96-02651A ASS'Y COLLECTOR ASS'Y - 1
DB96-02651B ASS'Y COLLECTOR ASS'Y 1 -
28 DB96-03825A ASS'Y INLET ASS'Y - 1
DB96-05596A ASS'Y INLET ASS'Y 1 -
29 DB61-01157A BRACKET EVAP SGCC-M 1 1
30 DB63-00624A COVER EVAP ABS 1 1
31 DB31-00179A MOTOR FAN ASS'Y(OSME-254SAC) 1 1
32 DB67-00260A BLOWER ABS 2 2
33 DB61-01160A CASE FAN UP ABS 2 2
34 DB63-00611A COVER MOTOR SGCC-M 2 2
35 DB61-01162A HOLDER MOTOR SGCC-M 4 4
36 DB63-00738A GUARD SAFETY HSWR 1 1
37 DB63-00739A GUARD FAN HSWR 2 2
38 DB67-00257A DRAIN PAN ABS 1 1
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
