Samsung mini DVM Series User Manual

Electrical Parts List
6-44Samsung Electronics
■ MAIN PCB : DB93-02779D(cont.)
C811 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C812 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C813 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C814 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C815 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C816 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C817 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C911 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C912 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C913 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C914 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
CD11 0406-001086 DIODE-TVS ST02D-200,185/200/215V,200W,DO-214 1 SNA
CD12 0406-001086 DIODE-TVS ST02D-200,185/200/215V,200W,DO-214 1 SNA
CD31 0406-001109 DIODE-TVS SAC5.0,7.6/-/-V,500W,DO-15 1 SNA
CD32 0406-001109 DIODE-TVS SAC5.0,7.6/-/-V,500W,DO-15 1 SNA
CD33 0406-001109 DIODE-TVS SAC5.0,7.6/-/-V,500W,DO-15 1 SNA
CD34 0406-001109 DIODE-TVS SAC5.0,7.6/-/-V,500W,DO-15 1 SNA
CN31 3711-000177
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,RED 1 SNA
CN32 3711-000176
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,BLU 1 SNA
CN41 3711-004379
HEADER-BOARD TO CABLE BOX,4P,1R,2mm,STRAIGHT,SN,NTR 1 SNA
CN42 3711-003942
HEADER-BOARD TO CABLE BOX,2P,1R,2mm,STRAIGHT,SN,WHT 1 SNA
CN43 3711-000178
HEADER-BOARD TO CABLE
1WALL,2P,1R,3.96mm,STRAIGHT,SN,WHT 1 SNA
CN44 3711-000879
HEADER-BOARD TO CABLE BOX,3P,1R,2.5mm,STRAIGHT,SN,BLU 1 SNA
CN45 3711-004349
HEADER-BOARD TO CABLE BOX,3P,1R,2mm,STRAIGHT,SN 1 SNA
CN61 3711-004484
HEADER-BOARD TO CABLE BOX,5P,1R,2mm,STRAIGHT,SN,NTR 1 SNA
CN62 3711-001001 CONNECTOR-HEADER BOX,5P,1R,2.5mm,STRAIGHT,SN,BLU 1 SNA
CN63 3711-000999
HEADER-BOARD TO CABLE BOX,5P,1R,2.5mm,STRAIGHT,SN,WHT 1 SNA
CN71 3711-003404
HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLU 1 SNA
CN72 3711-000262
HEADER-BOARD TO CABLE 1WALL,3P,1R,7.92mm,STRAIGHT,SN,WHT 1 SNA
CN73 3711-000203
HEADER-BOARD TO CABLE 1WALL,2P/3P,1R,7.92mm,STRAIGHT,SN,WHT 1 SNA
CN91 3711-004122
HEADER-BOARD TO CABLE BOX,14P,1R,2mm,STRAIGHT,SN 1 SNA
CN93 3711-004182 CONNECTOR-HEADER BOX,10P,1R,2mm,STRAIGHT,SN,NTR 1 SNA
D101 0402-001194 DIODE-RECTIFIER SHG2D,200V,2A,-,TP 1 SNA
D901 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP 1 SNA
D902 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP 1 SNA
D903 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP 1 SNA
D904 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP 1 SNA
D905 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP 1 SNA
D906 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP 1 SNA
D907 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
