Product Specifications
✳ 1) Nominal cooling capacities are based on:
✳ 1) - indoor temperature : 27˚C DB, 19˚C WB,
✳ 1) - outdoor temperature : 35˚C DB, Equivalent refrigerant piping : 10m(horizontal)
✳ 2) Nominal heating capacities are based on:
✳ 1) - indoor temperature : 20˚C DB,
✳ 1) - outdoor temperature : 7˚C DB, 6˚C WB Equivalent refrigerant piping : 10m(horizontal)
Indoor Unit (cont.)
■ Duct type(Low pressure)
Model
Power supply
Remark
Performance
Power
Piping connections
Set Size
Function /
Option
Cooling
✻
1)
Heating
✻
2)
Model
Type
Output
Air flow rate(Cool/Heat)
-
-
Liquid(Flare)
Gas(Flare)
Drain
Capacity
Sound Level
✻
3)
Fan motors
Running current
Power input
Refrigerant Control
Net weight
Shipping weight
Net dimension (WxHxD)
Shipping dimension(WxHxD)
Auto restart
Auto change over
Centralized controller (On/Off)
Group/Individual control for R/C
Troubleshooting by L.E.D
Max. installation ceiling height
Drain pump
AVXDLH071E✳ AVXDLH090E✳ AVXDLH112E✳ AVXDLH128E✳ AVXDLH140E✳
1, 220~240, 50
24,300 31,000 38,000 44,000 48,000
7.1 9.0 11.2 12.8 14.0
27,300 34,100 43,000 47,000 54,000
8.0 10.0 12.5 13.8 16.0
42/44 42/44 40/44 42/44 43/44
OSME-2454SAC(S331) OSME-2454SAC(S331) OSME-1186SAC(S332) OSME-2454SAC(S331) OSME-2454SAC(S331)
Sirocco Sirocco Sirocco Sirocco Sirocco
175 175 118 175 214
33/34 33/34 29/30 33/34 36/37
1.6 1.6 0.91 1.6 1.8
350 350 200 350 380
EEV(Electronic Expansion Valve)
9.52 9.52 9.52 9.52 9.52
15.88 15.88 15.88 15.88 15.88
VP 25, external diameter 32, internal diameter 25
66 66 66 66 66
77 77 77 77 77
1,110x390x650 1,110x390x650 1,110x390x650 1,110x390x650 1,110x390x650
1,329x512x829 1,329x512x829 1,329x512x829 1,329x512x829 1,329x512x829
Yes Yes Yes Yes Yes
No No No No No
Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes Yes Yes Yes Yes
410 410 410 410 410
Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Heat pump
Btu/h
kW
Btu/h
kW
dB
-
-
W
m
3
/min
A
W
mm
mm
mm
kg
kg
mm
mm
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
mm
Yes/No
ø, V, Hz
