Samsung mini DVM Series User Manual

Disassembly and Reassembly
Samsung Electronics4-11
No Parts Procedure Remark
5) After removing screws, separate the
cover from the Panel as shown in the
picture.
6) Separate the Step Motor that connected
to the Indoor Unit and Remote Control
Receiving Part connector.
7) Pull back the both side hooks of the
Panel and separate the Panel from the
Indoor Unit.
