OfficeServ 7400 INSTALLATION
TECHNICAL MANUAL PART 3 MAY 2010
3.2
OS7200 HARDWARE MIGRATION TO THE OS7400
The OfficeServ 7200 cabinet can be used as expansion cabinet 1 and/or expansion cabinet 2 for the
OfficeServ 7400 system. Simply install an OS7200 LCP card in slot 0 of the cabinet and connect it to
the MP40 via LCP link cable. The OS7200 cabinet cannot be used as a main cabinet for an OS7400
system. Most of the OfficeServ 7200 cards are common with the OfficeServ 7400 with a few
exceptions. Refer to Table 3.1 to see the card/slot compatibility rules. The possible cabinet
combinations are shown below.
