OfficeServ 7400 INSTALLATION
TECHNICAL MANUAL PART 3 MAY 2010
3.49
Ports & LEDs Function Description
RUN LED This LED indicates MP40 status.
- Off: Power is not being supplied.
- On: Booting.
- Blink: The RAM program is operating.
LAN Tx LED This LED indicates the transmit status of the LAN port.
- Off: Data is not being transmitted.
- On or blink: Data is being transmitted.
LAN Rx LED This LED indicates the receive status of the LAN port.
- Off: Data is not being received.
- On or blink: Data is being received.
SVC LED This LED indicates if the service is being offered.
- This LED blinks when program is being modified or configuration is being
loaded.
DSP LED This LED indicates if the VoIP DSP is operating.
- This LED blinks when the VoIP channels are engaged.
RTPT LED This LED indicates if the voice packets are being forwarded.
- This LED turns on when the voice packets are forwarded.
RTPR LED This LED indicates if the voice packets are being received.
- This LED turns on when the voice packets are received.
