Samsung OfficeServ 7400 - Page 67

OfficeServ 7400 INSTALLATION
TECHNICAL MANUAL PART 3 MAY 2010
3.51
Table 3.23 OAS Front Panel Components
Ports & LEDs Function Description
LAN Port that connects the Ethernet.
SIO Serial Port (for Samsung Use ONLY)
RST Button for resetting the OAS.
PWR LED This LED indicates the power supply status.
- Off: Power is not being supplied.
- On: Power is being supplied properly.
RUN LED This LED indicates MP40 status.
- Off: Power is not being supplied.
- On: Booting.
- Blink: The RAM program is operating.
LAN Tx LED This LED indicates the transmit status of the LAN port.
- Off: Data is not being transmitted.
- On or blink: Data is being transmitted.
LAN Rx LED This LED indicates the receive status of the LAN port.
- Off: Data is not being received.
- On or blink: Data is being received.
SVC1 LED This LED indicates if the service is being offered.
- This LED blinks when program is being modified or configuration is being
loaded.
SVC2 LED
This LED indicates if the service is being offered.
- This LED blinks when program is being modified or configuration is being
loaded.
SVC3 LED
This LED indicates if the service is being offered.
- This LED blinks when program is being modified or configuration is being
loaded.
SVC4 LED
This LED indicates if the service is being offered.
- This LED blinks when program is being modified or configuration is being
loaded.
