OfficeServ 7400 INSTALLATION
TECHNICAL MANUAL PART 5 MAY 2010
5.3
Table 5.1 Consumption Per Device
CARD Name
Device
Type
Current Consumption
for Each Device (mA)
16DLI2 2-Line LCD Keyset 25
16SLI2
16MWSLI
Analog Phone 25
MW Phone 30
PLIM/PLIM2 or
GPLIM
(current drawn
from connected
devices)
ITP-5021D, ITP-5107S, ITP-5121D 100
ITP-5112L 130
SMT-R2000 Dual AP 200
SMT-i3105 83
SMT-i5210 127
SMT-i5220, SMT-i5230 107
SMT-i5243 156
SMT-i5264 100
DATA
(current drawn
from modules)
GWIM/GWIMT 450
GSIM/GSIMT 320
GPLIM/GPLIMT 35
IF ADDING GPLIM/GPLIMT/PLIM/PLIM2 CONNECTED DEVICES, GWIM/GWIMT OR
GSIM/GSIMT MODULES CAUSE CURRENT DRAWN TO EXCEED 6600mA PER CABINET (not
per system), THEN YOU MUST CONNECT THE OS7150 EXTERNAL PoE POWER SUPPLY
MODULE TO THE CABINET.
It is important to note that the OS7150 can only provide additional power to the PLIM, PLIM2,
GPLIM/GPLIMT, GWIM/GWIMT and GSIM/GSIMT. The OS7150 is used when the GSIM/GSIMT,
GWIM/GWIMT or PoE devices connected to GPLIM/PLIM causes the total current draw per
cabinet to exceed 6600mA. It does not provide power to DLI ports, MWSLI ports and other
system interface cards.
The internal jumpers must be set correctly for the four modules mentioned above to use the
external OS7150 PoE power supply.
PRODUCT SAFETY
Electric Shock
Make sure to turn this product OFF when handling this product. Handling this product with
AC power ON may cause electric shock.
