If you select “EVERY START-UP”, the wizard appears whenever the Penta drive is powered on;
if yo
u select “ONLY NOW”, you can scroll through the menu and the wizard is disabled as soon as you
quit the menu;
if you select “NEXT START-UP”, the menu is displayed only when the Penta drive is next started up;
if you select “NEVER”, the Start-Up menu is disabled.
Parameters included in the Start-Up menu:
Type of control algorithm
Speed feedback from encoder [only if FOC is active]
Type of V/f pattern [only if IFD is active]
No-load current of the motor [only if FOC is active]
Voltage preboost [only if IFD is active]
Current limit while accelerating
Current limit at constant rpm
Current limit while decelerating
Torque limit [only if VTC/FOC are active]
Encoder operating mode [only if FOC is active]
Encoder A pls/rev [only if FOC is active]
Encoder B pls/rev [only if FOC is active]
Autotuning selection [only if VTC/FOC are active]
Motor tuning selection [only if VTC/FOC are active]
Motor thermal time constant [only if protection is active]
