Machine Operation SY16C Excavator OMM
4-14 Operation and Maintenance Manual — 0420 SANY
SEAT AND SEAT BELT
This machine has an operator seat with seat position, seat weight suspension, and seat backrest adjustments.
Seat Forward/Backward Adjustment
When seated, lift the position adjustment lever (1) on the
front of the seat. Slide the seat forward or backward to the
desired position and release the lever to lock the seat in
place.
Seat Backrest Angle Adjustment
Lift the backrest angle adjustment lever (1) on the left side
under the backrest and move the backrest forward or
backward to the desired position. Release the lever. The
backrest will lock in the desired position.
Fig. 4-11
0005101
1
Fig. 4-12
0003835
1
