PLC-HP7000L Basic Serial Command Functional Specifications
7/27
4. Functional Execution Command Table
Command
Item
Command
Item
C00 POWER ON C20 BRIGHTNESS +
C01
POWER OFF
(QUICK POWER OFF)
C21 BRIGHTNESS -
C02 POWER OFF C22 ---
C03 --- C23 INPUT 2 VIDEO
C04 --- C24 INPUT 2 Y,Pb/Cb,Pr/Cr
C05 INPUT 1 C25 INPUT 2 RGB
C06 INPUT 2 C26 ---
C07 INPUT 3 C27 IMAGE
C08 NETWORK C28 Direct on Enable
C09 --- C29 Direct on Disable
C0A --- C2A POWER MANAGEMENT READY1
C0B --- C2B POWER MANAGEMENT OFF
C0C --- C2C POWER MANAGEMENT READY2
C0D VIDEO MUTE ON C2D ---
C0E VIDEO MUTE OFF C2E
POWER MANAGEMENT SHUT DOWN
C0F SCREEN NORMAL SIZE C2F ---
C10 SCREEN FULL SIZE C30 D.ZOOM +
C11 --- C31 D.ZOOM -
C12 --- C32 ---
C13 --- C33 INPUT 3 VIDEO
C14 --- C34 INPUT 3 S-VIDEO
C15 --- C35 INPUT 3 Y,Pb/Cb,Pr/Cr
C16
---
C36 ---
C17
---
C37 ---
C18
---
C38 ---
C19
---
C39 ---
C1A --- C3A POINTER RIGHT
C1B --- C3B POINTER LEFT
C1C MENU ON C3C POINTER UP
C1D MENU OFF C3D POINTER DOWN
C1E DISPLAY CLEAR C3E ---
C1F --- C3F ENTER
“---“ means “No Function”.
To Next Page
