Sanyo PLC-XE32

-32-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
15 DXOUTR (H Screen Position) 473 0 - 1023
16 DXOUTG (H Screen Position) 473 0 - 1023
17 DXOUTB (H Screen Position) 473 0 - 1023
18 ENBX*R Phase 4 0 - 127
19 ENBX*G Phase 4 0 - 127
20
ENBX*B Phase 4 0 - 127
21
ENBX*(RGB) Width 3 0 - 63
22
h_change_pos (CLY
H-Position)
28 0 - 31
23
DYOUTR (V Screen Position) 22 0 - 511
R and B linked to G24 DYOUTG (V Screen Position) 22 0 - 511
25
DYOUTB (V Screen Position) 22 0 - 511
26
dxout_base_pos 1 0-1
27
sh_base_pos_b (SH Position) 546 0 - 4095
28
NRG Position 48 0 - 127
29
NRG Width 119 0 - 255
30 OSD (Insert Position) 2 0 - 3
31 OSD (Pattern Selection) 0 0 - 7
32
GAMMA(ON/OFF) 1 0 - 1
33 ref_gate_pos (NRS Position) 49 0 - 1023
34 ref_gate_dur (NRS Width) 186 0 - 1023
35 gray_on 7 0 - 7
36 Compensations 0 0 - 1
37 Crosstalk Compensation EN 0 0 - 1
38
V-Line Shading DC Oset
Comp. EN
Normal-Mount / Rear-Ceiling 0 / 0 0 - 1
39
V-Line Shading Oset Comp.
EN
Normal-Mount / Rear-Ceiling 1 / 1 0 - 1
40 V-Line Shasing BLSP_EN Normal-Mount / Rear-Ceiling 1 / 1 0 - 1
41
Sequetial Ghost
Compensation EN
Normal-Mount / Rear-Ceiling 1 / 1 0 - 1
42
Block Ghost Comp. EN 0 0 - 1
43 Reverse Ghost Comp. EN 0 0 - 1
44 Back crosstalk Comp. EN 0 0 - 1
45 R_base_pos 4 0 - 15
R and B linked to G46 G_base_pos 4 0 - 15
47 B_base_pos 4 0 - 15
48 RGB_adjust 0 0 - 7
49 RGB_level 0 0 - 1023
50
V-Line Shading Comp. Value
Setting [R0]
Normal-Mount / Rear-Ceiling 5 / 4 0 - 255
51
V-Line Shading Comp. Value
Setting [R1]
Normal-Mount / Rear-Ceiling 2 / 3 0 - 255
52
V-Line Shading Comp. Value
Setting [R2]
Normal-Mount / Rear-Ceiling 1 / 0 0 - 255
53
V-Line Shading Comp. Value
Setting [R3]
Normal-Mount / Rear-Ceiling 0 / 255 0 - 255
54
V-Line Shading Comp. Value
Setting [R4]
Normal-Mount / Rear-Ceiling 255 / 253 0 - 255
55
V-Line Shading Comp. Value
Setting [G0]
Normal-Mount / Rear-Ceiling 7 / 4 0 - 255
56
V-Line Shading Comp. Value
Setting [G1]
Normal-Mount / Rear-Ceiling 4 / 3 0 - 255
57
V-Line Shading Comp. Value
Setting [G2]
Normal-Mount / Rear-Ceiling 1 / 0 0 - 255
58
V-Line Shading Comp. Value
Setting [G3]
Normal-Mount / Rear-Ceiling 0 / 255 0 - 255
59
V-Line Shading Comp. Value
Setting [G4]
Normal-Mount / Rear-Ceiling 255 /253 0 - 255
60
V-Line Shading Comp. Value
Setting [B0]
Normal-Mount / Rear-Ceiling 5 / 4 0 - 255
61
V-Line Shading Comp. Value
Setting [B1]
Normal-Mount / Rear-Ceiling 2 / 3 0 - 255
62
V-Line Shading Comp. Value
Setting [B2]
Normal-Mount / Rear-Ceiling 0 / 1 0 - 255
63
V-Line Shading Comp. Value
Setting [B3]
Normal-Mount / Rear-Ceiling 0 / 255 0 - 255
64
V-Line Shading Comp. Value
Setting [B4]
Normal-Mount / Rear-Ceiling 255 / 253 0 - 255
65 Ghost_R_pos (Sequential) 4 0 - 15
66 Ghost_G_pos (Sequential) 4 0 - 15
67 Ghost_B_pos (Sequential) 4 0 - 15
68 Ghost_R_center 5 0 - 2047
69 Ghost_R_start 128 0 - 255
70 Ghost_R_end 128 0 - 255
