Sanyo PLC-XE32

-33-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
71 Ghost_G_center 5 0 - 2047
72
Ghost_G_start 128 0 - 255
73 Ghost_G_end 128 0 - 255
74 Ghost_B_center 5 0 - 2047
75 Ghost_B_start 128 0 - 255
76 Ghost_B_end 128 0 - 255
77 R-Block Ghost 3 0 - 2047
78 G-Block Ghost 3 0 - 2047
79 B-Block Ghost 3 0 - 2047
80 R_base_level (Block) 0
81 G_base_level (Block) 0
82
B_base_level (Block) 0
83 Ghost_R_pos (Reverse) 3 0 - 2047
84 Ghost_G_pos (Reverse) 3 0 - 2047
85 Ghost_B_pos (Reverse) 3 0 - 2047
86 R_base_level (Reverse) 0 0 - 1023
87 G_base_level (Reverse) 0 0 - 1023
88 B_base_level (Reverse) 0 0 - 1023
89 C_TALK R 1022 0 - 1023
90 C_TALK G 1022 0 - 1023
91 C_TALK B 1022 0 - 1023
92
C_TALK_R_level 730 0 - 1023
93 C_TALK_G_level 730 0 - 1023
94 C_TALK_B_level 730 0 - 1023
95 C_TALK R_CENT 5 0 - 2047
96 C_TALK R_START 128 0 - 255
97 C_TALK R_END 128 0 - 255
98 C_TALK G_CENT 5 0 - 2047
99 C_TALK G_START 128 0 - 255
100 C_TALK G_END 128 0 - 255
101 C_TALK B_CENT 5 0 - 2047
102
C_TALK B_START 128 0 - 255
103 C_TALK B_END 128 0 - 255
104 lccom_correct_select 16 0 - 63
105 Hori Start 274 0 - 2047
106 Vert Start 31 0 - 2047
107 Hori End 1297 0 - 2047
108 Vert End 798 0 - 2047
109 R MIN 156 0 - 1023
110 R_MID2 382 0 - 1023
111 R_MID1 555 0 - 1023
112
R_MAX 661 0 - 1023
113 G MIN 156 0 - 1023
114 G_MID2 382 0 - 1023
115 G_MID1 555 0 - 1023
116 G_MAX 661 0 - 1023
117 B MIN 156 0 - 1023
118 B_MID2 382 0 - 1023
119 B_MID1 555 0 - 1023
120
B_MAX 661 0 - 1023
121
G_V1 (DAC) 143 0 - 511
122
R_V1 (DAC) 143 0 - 511
123
B_V1 (DAC) 143 0 - 511
124
REF_G (DAC) 100 0 - 511 * Black Reference Adjustment
125
REF_R (DAC) 100 0 - 511 * Black Reference Adjustment
126
REF_B (DAC) 100 0 - 511 * Black Reference Adjustment
127
G_LCCOM (L3E06100) 95 0 - 511 * Common Center Adjustment
128
R_LCCOM (L3E06100) 95 0 - 511 * Common Center Adjustment
129
B_LCCOM (L3E06100) 95 0 - 511 * Common Center Adjustment
130 SyncPosition 0 0 - 1
Link with 130 and 131
131 SyncVideoPosition 0 0 - 1
132
Color Shading SW 1 0 - 1
133
V-Line Shading Comp. Value
Setting [R1 dot]
Normal-Mount / Rear-Ceiling 17 /17 0 - 31 Center value is 16
134
V-Line Shading Comp. Value
Setting [R2 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
135
V-Line Shading Comp. Value
Setting [R3 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
136
V-Line Shading Comp. Value
Setting [R4 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
