Sanyo PLC-XE32

-34-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
137
V-Line Shading Comp. Value
Setting [R5 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
138
V-Line Shading Comp. Value
Setting [R6 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
139
V-Line Shading Comp. Value
Setting [G1 dot]
Normal-Mount / Rear-Ceiling 17 /17 0 - 31
140
V-Line Shading Comp. Value
Setting [G2 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
140
V-Line Shading Comp. Value
Setting [G3 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
142
V-Line Shading Comp. Value
Setting [G4 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
143
V-Line Shading Comp. Value
Setting [G5 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
144
V-Line Shading Comp. Value
Setting [G6 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
145
V-Line Shading Comp. Value
Setting [B1 dot]
Normal-Mount / Rear-Ceiling 17 /17 0 - 31
146
V-Line Shading Comp. Value
Setting [B2 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
147
V-Line Shading Comp. Value
Setting [B3 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
148
V-Line Shading Comp. Value
Setting [B4 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
149
V-Line Shading Comp. Value
Setting [B5 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
150
V-Line Shading Comp. Value
Setting [B6 dot]
Normal-Mount / Rear-Ceiling 16 /16 0 - 31
Group
200
Option
0
Logo Prohibition (Forced No
Brand)
Logo Prohibition (0: Menu, 1: Forced, 2:
China, 3-9: not used)
0 0 - 2 Eective after AC On
1 RS232C Baudrate Baud Rate 0 0 - 2
0: 19200bps, 1: 9600bps, 2:
115200bps
2 PJLink Enable PJLink 0 0 - 1 0:Disable 1:Enable
3 Shipping Setting 0 0 - 20 Default set when the value is set to 10
4 CABLE SW Long Cable 0 0 - 10 0: Disable, 1: Enable
5 PW Debug Command Enable 0 0 - 1
0:Disable (Sanyo Serial Command
Eanble)
1: Enable (PW Debug Mode)
6 Device Refresh Disable 0 0 - 1
0:Enable, 1:Disable
No last memory
7 Device Access Disable 0 0 - 1
0:Enable (Normal), 1:Disable
No last memory
20
Projector Time Reset 0 0 - 20
Projector Time is cleared when the
value is set to 10
21
Lamp Warning Time
(NORMAL)
Lamp Life at Normal Mode (Warning
Time at Normal)
500 - 8000
22 Lamp Warning Time (ECO)
Lamp Life at Eco Mode (Warning Time
at Eco)
500 - 8000
23
Lamp Warning Time (HIGH)
Lamp Life at High Mode (Warning Time
at High)
500 - 8000
30 Lamp life test enable 0:Disable 1:Enable, for safety test only
31 Lmap On time(for life test) For test purpose
32
Lamp O time(for life test) For test purpose
33 Lamp total time(for life test) For test purpose
40 PreScaler 0-255 n/a
41 Htime 0-65535 n/a
52
Lamp Counter reset Times Reset Times of Lamp Counter 0 0 - 255 Read only
54 Factory Default Execute Times Reset times of Fanctory Default 0 0 - 255 Read only
55 Motor Disable 0: On, 1: O 0 0 - 1
56 Menu Position Move menu (X asis) 0 0 - 1024
57 Menu Position Move menu (Y asis) 0 0 - 1024
60 Spread Spectrum Enable 1 0 - 1 0: O, 1: On
61 Spread Spectrum Frequency 80 0 - 500
62
Spread Spectrum Amplitude 100 0 - 300
70 R/C Mode setting
0 : Standard R/C Mode 1: Promethean
R/C mode
1 0 - 1
Group
201
Option (signal)
0 FrameLock Option 0 0 - 1
0: FrameLockOFF at PC signal
1: FrameLockON at PC signal and 47Hz
(Vfreq) ~ Panel frequency of input
signal
2 Field Sense Invert Enable 0 0 - 1
Reverse Processing of FLDINVSetting
Value
0: Disable - Used FLDINV Setting Value
1: Enable - Used Reversed FLDINV
Setting Value
