Sanyo PLC-XE32

-37-
Group/
Item
Item Name Function Initial Range Note
73 HINOR_VALU_FAN2_MAX
FAN2 Control Max Value in High-land
Normal
115 0-255
74 CLHIGH_TEMP_FAN1_MIN
FAN1 Control Start Temperature in Ceiling
High
29 0-255
75 ClHIGH_TEMP_FAN1_MAX
FAN1 Control End Temperature in Ceiling
High
39 0-255
76 CLHIGH_TEMP_FAN2_MIN
FAN2 Control Start Temperature in Ceiling
High
29 0-255
77 CLHIGH_TEMP_FAN2_MAX
FAN2 Control End Temperature in Ceiling
High
39 0-255
78 CLHIGH_VALU_FAN1_MIN FAN1 Control Min Value in Ceiling High 70 0-255
79 CLHIGH_VALU_FAN1_MAX FAN1 Control MaxValue in Ceiling High 135 0-255
80 CLHIGH_VALU_FAN2_MIN FAN2 Control Min Value in Ceiling High 80 0-255
81 CLHIGH_VALU_FAN2_MAX FAN2 Control MaxValue in Ceiling High 130 0-255
82
CLNOR_TEMP_FAN1_MIN
FAN1 Control Start Temperature in Ceiling
Normal
30 0-255
83 CLNOR_TEMP_FAN1_MAX
FAN1 Control End Temperature in Ceiling
Normal
38 0-255
84 CLNOR_TEMP_FAN2_MIN
FAN2 Control Start Temperature in Ceiling
Normal
30 0-255
85 CLNOR_TEMP_FAN2_MAX
FAN2 Control End Temperature in Ceiling
Normal
38 0-255
86 CLNOR_VALU_FAN1_MIN FAN1 Control Min Value in Ceiling Normal 60 0-255
87 CLNOR_VALU_FAN1_MAX FAN1 Control MaxValue in Ceiling Normal 125 0-255
88 CLNOR_VALU_FAN2_MIN FAN2 Control Min Value in Ceiling Normal 60 0-255
89 CLNOR_VALU_FAN2_MAX FAN2 Control MaxValue in Ceiling Normal 115 0-255
90 FAN_1_AUTO_ADJ 0: OFF (Manual), 1: ON (Auto) - 0-1
91 FAN_2_AUTO_ADJ 0: OFF (Manual), 1: ON (Auto) - 0-1
92
FACTORY_STD_FAN_VOL_MIN
For Factory Adjustment Ref FAN Voltage
Min (Initial 5V)
50 0-255
93 FACTORY_STD_FAN_VOL_MAX
For Factory Adjustment Ref FAN Voltage
Min (Initial 13.5V)
135 0-255
94 FAN1_ADJUST_VOLT_MIN
For Factory Adjustment FAN1 Drive Volt-
age Min
40 0-255 * Fan Voltage adjustment
95 FAN1_ADJUST_VOLT_MAX
For Factory Adjustment FAN1 Drive Volt-
age Max
210 0-255
* Fan Voltage adjustment
96 FAN2_ADJUST_VOLT_MIN
For Factory Adjustment FAN2 Drive Volt
-
age Min
10 0-255 * Fan Voltage adjustment
97 FAN2_ADJUST_VOLT_MAX
For Factory Adjustment FAN2 Drive Volt
-
age Max
210 0-255
* Fan Voltage adjustment
98
TEMP_ERROR_DETECT_MAX_
TIMES
Temp Failure when The Sensor detects an
error X times sequentially
5 1-9
99 FAN_1_MIN_VOL_LAMP_DIFF
Up Volume of FAN1 Control Min
(Unit Vx10)
0 0-20
100 FAN_2_MIN_VOL_LAMP_DIFF
Up Volume of FAN2 Control Min
(Unit Vx10)
0 0-20
101 LAMP_VOL_BORDER_LINE
Threshold Lamp Volatge of the above
items
(Unit Vx10)
70 30-90
102
LAMP_VOL
Current Lamp Voltage (V)
(Effective 30 sec. after turn on)
- 0-255 * Read only
103 Dimmer Voltage Change Cycle
Voltage Change Cycle at Dimmer (Unit:
sec)
3 1-?
104 Dimmer Average Check Period Measuring Time at Dimmer (Unit: sec) 10 1-?
105 Dimmer Voltage Change rate
Voltage Change Volume at Dimmer (Unit:
0.1V)
1 1-?
106 Dimmer Average Avarage Value of Dimmer - - * Read only
107 Last Voltage Difference Last Voltage defferential Value - - * Read only
108 Voltate Difference Goal
Target Voltage Dif. Value at Dimmer (Unit:
10V)
- - * Read only
109 Temp Diff High 0
110 Temp Diff Normal 0
111 Temp Diff High High 0
112
Temp Diff Normal High 0
113 Temp Diff High Ceil 0
114 Temp Diff Normal Ceil 0
115 Temp Up Time High 0
116 Temp Up Time Normal 0
117 Temp Up Time High High 0
118 Temp Up Time Normal High 0
119 Temp Up Time High Ceil 0
120
Temp Up Time Normal Ceil 0
121
Standby Cooling Check Cycle 5
122
Standby Cooling Start Threshold 54
123
SAfter Shutdown Cooling 1 0: No, 1: Yes
124
OnStart Cooling Start Threshold 38 0-100
Group 260
Auto Calibration (Commn) * Auto Calibration
0 Execute Calibration 0 0 - 1
Executes Auto-Calibration when
changiing the Value (PC White 100%)
1 Loop Count
Maximum Execution Times (OFFSET-
>GAIN)
10 1 - 30
2 Auto Status Result of Auto-Calibration (Last Memory) 0 0 / 1 / 9 0: OK, 1: Adjusting,2: Error * ReadOnly
3 AutoWait Wait Value for each setting 1 1 - 20
4 CHECK -Tolelance Torelance of OFFSET 2 1 - 255
Group 261
Auto Calibration (RGB)
0 OFFSET AREA H START Black Level Acquiring Area H-Start Position 975 0 - 1000
1 OFFSET AREA V START Black Level Acquiring Area V-Start Position 500 0 - 1000
2 GAIN AREA H START
White Level Acquiring Area H-Start
Position
25
0 - 1000
Electrical Adjustments
